System LO-NC

The LO-NC from PILOUS is an automated NC gauging device designed for accurate measuring and positioning of profile materials and lighter solid materials with smaller diameters. It combines servo-driven accuracy, touchscreen control and a robust roller conveyor base for efficient support of semi-automatic bandsaw operations.

The LO-NC is built around a massive L 400 or L 520 roller conveyor with an integrated industrial linear axle. Its servo motor provides fast movement and a measuring accuracy of 0.1 mm, while the backstop trolley moves along a linear guide system for stable and repeatable positioning.

The system allows frequently used lengths to be stored in memory and includes an intelligent backstop function that can move aside before cutting. If the material hits the backstop excessively, the NC-controlled system enables the backstop to move aside and then return to its set position.

The LO-NC is designed as an ideal companion for Pilous ARG 300–ARG 500 semi-automatic bandsaw machines and can be mounted on L 400 and L 520 roller conveyors.

The package includes backstop system with Automated NC Gauging, feeding system of appropriate length, control panel, conveyor.

Key points

• Automated NC gauging device
• Designed for profile materials and light solid materials
• Servo-driven measuring system
• Feeding accuracy of 0.1 mm
• Large 7″ HI-RES colour touchscreen
• Backstop trolley on linear guide system
• Memory storage for frequently used lengths
• Intelligent backstop jump-aside function
• Compatible with L 400 and L 520 roller conveyors
• Suitable for Pilous ARG 300–ARG 500 semi-automatic bandsaws

Technical advantages

Servo-controlled measuring accuracy

The LO-NC uses a BMH1001 servomotor with 1.26 kW motor power and 4000 rpm speed, delivering fast, accurate and repeatable material positioning.

Intelligent backstop operation

The backstop can move aside before cutting and return to the set position automatically. This improves workflow safety and reduces the risk of collision or overload during cutting operations.

Touchscreen control

The large 7″ touchscreen interface simplifies operation, length setting and control. This reduces setup time and supports efficient day-to-day production.

Robust conveyor integration

The system is built on L 400 or L 520 conveyors, with roller widths of 400 mm or 520 mm, roller diameter of 58 mm and load capacity of 500 kg/m.

Flexible length options

The LO-NC is available in conveyor lengths of 3 m, 4 m, 5 m and 7 m, with measured lengths of 2400 mm, 3400 mm, 4400 mm and 6400 mm.

Applications

The LO-NC is suitable for:

• Semi-automatic bandsaw cutting lines
• Profile material measuring
• Light solid material positioning
• Repetitive cutting operations
• Metal fabrication workshops
• Industrial production environments using Pilous ARG 300–ARG 500 machines

Why choose LO-NC

The LO-NC improves measuring accuracy, reduces manual setting time and increases repeatability in semi-automatic cutting operations. Its servo-driven system, touchscreen control and intelligent backstop functionality make it a strong productivity upgrade for workshops using compatible Pilous bandsaw machines.
